| Resolution |
Up to 100,000 divisions, Min of 0.25µV/Division |
| Zero Cancellation |
± 2mV/V |
| Span Adjustment |
0.1mV/V ~ 3mV/V |
| Stability/Drift |
Zero < 0.1µV/°C ( + 8ppm Deadload Max) |
| Span TC |
< 8ppm/°C |
| Linearity Error |
< 20ppm |
| Noise |
< 0.2µVp-p |
| Excitation |
7.4V for up to 16 x 350 or 32 x 700Ω Load Cells, (4-wire or 6-wire plus shield) |
| Max Total Load Cell Resistance |
1,000Ω |
| A/D Type |
24bit Sigma Delta with ± 8.388,608 internal Counts |
| Operating Environment |
-10 ~ 50°C Ambient Temperature, < 90% Non-Condensing Humidity, -20 ~ 50°C Ambient Storage
IP55 when panel mounted, or with rear boot (otherwise IP40) |
| Case Materials |
ABS, Silicone Rubber, Nylon, Acrylic (no halogen used) |
| Packing Weight |
Basic Indicator 0.6kg |
| Battery Backed Clock Calendar |
Battery Life 10 Years Minimum |
| Assignable Function Keys |
Printing, Unit Switching, Counting, Manual Hold, Peak Hold, Totalising. |
|
| LCD (with 4 Alpha-numeric Displ |
LED Backlit |
| Primary Display |
6 x 28.4mm High Digits with Units & Annunciators |
| 2nd Display |
9 x 17.6mm digits with units |
| 3rd Display |
8 x 6.1mm digits |
| 4th Display |
4 x 7.6mm digits |
| Setup & Calibration |
Full Digital. Visual Prompting In Plain Messages |
| Digital Filter |
Sliding Window Average |
| Zero Range |
0.1 ~ 30 seconds, Adjustable ±2 ~ 20% Full Capacity |
| Standard Power Input |
12 ~ 24V DC (15 VA max) |
| ON/OFF Key |
With Memory Feature |
| Variants |
110/240V AC 50/60HZ Input |
| Optical Data Communications |
Magnetically coupled optical communications support with optional conversion cable which connects directly into a standard USB or RS-232 Port |
| Correction |
Ten Point Linearity Correction |
| Serial Outputs (Standard) |
RS-485 transmit only for remote display, RS-232 serial port for remote display, network or printer. Supports transmission rate: 2400, 4800, 9600 or 19200 Baud |
|
